Spatial instruments · WGS 84

Land surveying instruments
that run in your browser.

Elevation cross-sections, parcel areas from survey coordinates and cadastral unit conversion — evaluated on the WGS 84 ellipsoid, exported as CSV, JSON or a PDF field report. No account, no upload, no server-side compute.

Karney geodesics Gaussian shoelace UTM 1–60 · CSF ground area pdf-lib reports

Terrain cross-section from a 2.4 km traverse Elevation profile rising from 1 680 metres to a 2 148 metre summit and descending to 1 802 metres, with station markers and a distance scale. 1 700 1 800 1 900 2 000 2 100 m 0.0 0.6 1.2 1.8 2.4 km A · 1 680 B · 1 802 2 148 m traverse 2.40 km · gain 468 m · max grade 12.4 %
Fig. 1 — Cross-section, 2.40 km traverse Gain 468 m · max grade 12.4 %

Workspace

Three instruments, one bench

Terrain Profile opens by default. Switch instruments without losing what you have already measured — each tab holds its own state for the session.

Terrain profileWGS 84Client-side

Elevation source

Map or manual

Click the map to set A, then B. Prefer typing? Coordinates accept decimal degrees or DMS.

e.g. -1.2864

e.g. 36.8172

Sampling

20–200 samples

Smoothingmoving average

Elevations are fetched in batches of 100 from the Geodesia edge service first, then Open-Meteo, and cached for this session. A failed lookup never discards your input.

Map

WGS 84 basemap

Basemap: Geodesia edge cache — loading tiles…

Loading basemap…
No endpointsClick to set A

Click A, then B. The profile samples the WGS 84 geodesic between them. Keyboard alternative: type coordinates in the panel.

Profile metrics

Awaiting input

No profile computed yet

Set two points on the map, draw a route, or upload a table with distance and elevation columns. Metrics appear here as soon as the profile is sampled.

Category thresholds · flat < 2% · gentle < 5% · rolling < 10% · hilly < 20%
Elevation profile

No profile yet. Pick two points on the map, draw a route or upload a CSV with distance and elevation columns.

Station table

No data

No station data

Stations appear once a line, route or uploaded table has been sampled.

Ecosystem · App directory

The Geodesia platform

Geodesia is the hub for a set of decoupled, single-purpose spatial applications. Each runs on its own subdomain, keeps its own release cadence, and is launched from here.

Showing 3 of 3 applications.

  • Geodesia Core

    geodesia.online
    LIVEClient-Side Execution

    Terrain profiles, polygon area and closure, and land-unit conversion in one client-side workspace.

    WGS 84 geodesic inverse (Karney) · hand-rolled SVG profile chart · CSV / JSON / PDF reports

    • Terrain profile
    • Polygon area
    • Land converter
    Open workspaceRuns in your browser
  • TerraFact

    landiq.geodesia.online
    BETAClient-Side Execution

    AI crop-suitability analysis (published as Land IQ) over browser-local Cloud-Optimized GeoTIFFs, clipped to a drawn parcel.

    COGs read in the browser · polygon clipping · no raster upload · suitability scoring

    • Crop suitability
    • Browser-local COGs
    • Parcel clipping
  • MethodFlow

    methodflow.geodesia.online
    LIVEClient-Side Execution

    Thesis methodology flowchart generator for research protocols, exporting publication-ready diagrams.

    LaTeX / TikZ · Word DOCX · Mermaid · deterministic layout

    • Methodology flows
    • LaTeX/TikZ
    • Word export

Method statement

How the numbers are produced

Every figure is derived from a named, published formula, and every report states which one produced which result. Nothing is approximated silently.

Planar area · Gaussian shoelace

A = ½ · |Σi (xi·yi+1 − xi+1·yi)|

The trapezoid form of the shoelace formula, evaluated on vertices in metres. It is exact for the numbers as drawn on a planar grid, independent of ring orientation, and is the correct check against a CAD parcel or a printed plan.

Ground area · WGS 84 geodesic

Aellipsoid = Σ Δλ · (2·E + sin α1 + sin α2) · b²/2

Polygon area on the ellipsoid using Karney’s series (GeographicLib). Legs are measured as inverse geodesic distances with forward and back azimuths, so the result is the area on the ground rather than on a projection. A spherical approximation is not adequate at cadastral scale; it is deliberately not offered.

Projected grid · UTM & combined scale factor

k = k0 · (1 + x²/(2R²)) · CSF = k · a/(a + h) · Aground = Agrid / CSF²

UTM eastings and northings from any zone (1–60, hemisphere-aware) are measured on the projected grid. The combined scale factor comes from the parcel’s distance to the central meridian (x) and the mean elevation (h), or from a survey-supplied value; ground area is the grid area divided by CSF², which is why the figure on a plan and the figure on the ground are not the same hectare.

Elevation profile statistics

Δsi = si+1 − si · grade % = 100 · Δh/Δs · gain = Σ max(0, Δh)

Stations are sampled along the geodesic at a fixed interval, so distance accumulates on the ellipsoid rather than in degrees. Climb and descent are separate accumulations of the positive and negative elevation differences; gradient is derived per segment and the maximum reported with the station where it occurs.

Engine specification

Datum / ellipsoid
WGS 84
Ellipsoid constants
a = 6 378 137 m · 1/f = 298.257223563
Area methods
Shoelace (planar) + Karney geodesic
Distance method
Inverse geodesic on WGS 84 for the ellipsoidal surface; planar distance and grid bearing on projected UTM or X/Y coordinates
Runtime
Browser (client-side; no data leaves the device)
Exports
CSV · JSON · PDF

01

Named formulas, printed with the result

Each instrument states the method that produced each figure — Gaussian shoelace, Karney geodesic series, inverse geodesic distance — instead of hiding it behind a black box.

02

Client-side execution

No upload endpoint exists. Coordinates and dropped files are read with the File API and evaluated in the tab.

03

Reproducible exports

CSV, JSON (geodesia.report/v1) and a PDF field report carrying parameters, method and an ISO-8601 timestamp.

04

Static, pre-rendered pages

Every method statement and feature breakdown is real HTML in the first response — no hydration wait before the text you came for.

05

Keyboard and screen-reader ready

Real labels on every input, focus rings that survive the dark theme, chart sampling by arrow key, and a manual coordinate path for every map action.

06

One ecosystem, separate releases

Geodesia is the hub for Land IQ and MethodFlow; each runs on its own subdomain and keeps its own cadence.

Questions

What engineers ask first

Short answers to the questions that decide whether a browser instrument is usable in real work. Anything unanswered: [email protected].

Is Geodesia free, and do I need an account?

Yes to both: every instrument is free to use and there is no account, sign-in or email gate. The tools run entirely in the browser tab, so there is no usage limit to meter and nothing to subscribe to.

Where does my survey data go?

Nowhere. Coordinates you paste, files you drop and results you compute stay in the browser tab — there is no upload step and no analytics or tracking script on the site. Two lookups do leave the device by design: map tiles from OpenStreetMap and elevation samples from the Open-Meteo elevation endpoint. Everything else, including all arithmetic, is local.

Which datum, ellipsoid and projection are used?

Geodesic calculations use WGS 84 with the defining constants a = 6 378 137 m and 1/f = 298.257223563. UTM coordinates are handled on WGS 84 transverse Mercator for any zone 1–60 in either hemisphere (false easting 500 000 m, false northing 10 000 000 m south, k0 = 0.9996), and local X/Y input is treated as a planar grid in metres with no implied projection.

Should I quote the grid, geodesic or ground area?

They answer different questions, so all three are printed. The grid area is the shoelace result on the projected coordinates — the figure that matches a plan, a CAD parcel or a UTM schedule. The geodesic area is the area on the ellipsoid and is the right figure for any statement about the land itself. The ground area divides the grid area by the combined scale factor squared (CSF = k · a/(a + h)), which is the figure a surveyor quotes after projection and elevation are removed. The difference between them is diagnostic: if it is larger than you expect, the projection or elevation assumption is wrong.

Can I paste UTM coordinates straight from a total station or Google Earth?

Yes — switch the reference system to UTM, set the zone and hemisphere, and paste easting, northing pairs one per line (CSV, tabs, or a spreadsheet paste all work). The tool measures the grid area and perimeter from those numbers directly, converts them to WGS 84 to add the geodesic and ground surfaces, and plots the ring on a coordinate sheet so a transposed pair or a missing corner is visible. Keep the whole parcel inside one zone: crossing a zone boundary puts the ring on two projections and the grid area stops being meaningful.

What does the terrain profile actually compute?

It accumulates geodesic distance between sampled stations along your line, differences the sampled elevations to get climb and descent, then derives gradient and a slope classification from each station-to-station segment. You get total distance, gain, descent, net change, minimum and maximum elevation, mean elevation, average and maximum gradient, and a station table that every headline figure can be traced back to. Elevations come from the Geodesia edge elevation service, with Open-Meteo as the fallback, so a survey sheet you upload is always the more authoritative source.

What can I export, and is it usable in a report?

Three artefacts per computation: a CSV of the raw and computed stations, a JSON verification document under the geodesia.report/v1 schema carrying the method statement and timestamp, and a PDF field report typeset client-side with pdf-lib. All three carry the tool name, parameters and an ISO-8601 timestamp so a reviewer can reproduce the result.

Is a Geodesia area a legally usable boundary survey?

No, and it does not claim to be. It is a planning, verification and coursework instrument: excellent for checking a computed figure, reconciling a deed area, or sanity-checking a consultant’s schedule — but only a licensed surveyor’s adjudicated survey can define a boundary.

Do the instruments work offline?

Once a page has loaded, all computation works without a network connection. Two features degrade gracefully offline: the map basemap needs tiles, and elevation sampling needs the elevation endpoint. In both cases the tools stay usable through manual coordinate entry and CSV/XLSX upload.
